THE PROTECTION AREA
THE PROTECTION RADIUS (Rp) OF A PREVECTRON 3® LIGHTNING CONDUCTOR IS CALCULATED ACCORDING TO FRENCH STANDARD NF C 17-102 : 2011, THUS :
Rp (h) = √2rh -h² + Δ(2r + Δ) for h ≥ 5m et
Rp= h x Rp (5)/5 for 2m ≤ h ≤ 5m
The protection radius depends on a number of factors :
- h(m) : is the height of the ESEAT tip over the horizontal plane through the furthest point of the object/area to be
- r(m) : 20 m, 30m, 45m or 60m according to the Protection Level I, II, III or IV assessed for the site using the Risk Analysis calculation (NF C 17-102 : 2011 Annex A).
- Δ (m) : Δ = Δ T x 106. Field experience has proved that is equal to the efficiency obtained during the ESEAT evaluation
PROTECTION RADIUS
PROTECTION LEVEL I : r = 20 m
|
H (m) |
2 |
3 |
4 |
5 |
10 |
|
S 60 |
31 |
47 |
63 |
79 |
79 |
|
S 50 |
27 |
41 |
55 |
68 |
69 |
|
S 40 |
23 |
35 |
46 |
58 |
59 |
|
TS 25 |
17 |
24 |
34 |
42 |
44 |
|
TS 10 |
10 |
15 |
21 |
26 |
28 |
PROTECTION LEVEL III : r = 45 m
PROTECTION LEVEL II : r = 30 m
|
H (m) |
2 |
3 |
4 |
5 |
10 |
|
S 60 |
34 |
52 |
68 |
86 |
88 |
|
S 50 |
30 |
45 |
60 |
76 |
77 |
|
S 40 |
26 |
39 |
52 |
65 |
67 |
|
TS 25 |
19 |
29 |
39 |
49 |
51 |
|
TS 10 |
12 |
19 |
25 |
31 |
34 |
PROTECTION LEVEL IV : r = 60 m
S range TS range
|
ADVANCED TRIGGERING |
T |
60 µs 50 µs 40 µs |
25 µs 10 µs |
|
DIMENSIONS |
Height |
654 mm |
609 mm |
|
Diameter (body) |
200 mm |
140 mm |
|
|
Diameter (Maxi) |
317 mm |
261 mm |
|
|
Diameter (rod) |
20 mm |
20 mm |
|
|
WEIGHT |
kg |
6,9 kg 6,3 kg 6,0 kg |
5,0 kg 4,8 kg |
|
CONNECTION |
Thread |
M20 |
M20 |
Substantiating its compliance and reliability requires multiple standard references, test campaigns and field tests, conducted by our R&D engineers in more than 20 countries, from artic to tropical areas.
Lightning is a natural phenomenon. Lightning air terminals are exposed to a very large range of events: extreme climatic conditions (temperatures, humidity…), high intensity electrical shocks up to several hundreds of thousands of Amperes, unpredictable lightning frequency…
Lightning Protection standards such as NF C 17 102, UNE 21 186 or NP4426 include detailed testing procedures that covers such extraordinary tough conditions. The PREVECTRON 3® Connect successfully passed these series of tests. Its integrated Lightning Counter was also tested according to the IEC 62 561 – 6 Edition 2 standard, confirming its full compliance to all relevant standards in the industry.
Lastly, the IoT connected system requires specific attention to work in severe electro-magnetic lightning conditions and meet the CE marking requirements. INDELEC develops dedicated testing processes, both in the LiRi Lab and in real lightning conditions, to confirm the PREVECTRON 3® Connect compatibility in such environment.
*UL Certification limited to Prevectron3 ESE
